Desander
The production can be widely applied in the triple-process cleanse of the drilling fluid and when it is used efficiently, it can effectively clear the suspended solid-phase granules with more than 30 microns in the drilling fluid. It is one indispensable device for stabilizing and adjusting the drilling fluid technical parameters. It can be used together with the sealed circulatory system of the drilling fluid.
Features of Desander
· Desander Options with shaker and without shaker for flexible application.
· Desander Cyclone PU material with better Abrasion resistance.
· No under shaker design structure compact and assembly flexible.
· Mini desander cleaner with shaker for both weighted/unweighted mud in various drilling Usages
· Desander is placed after shakers and degasser but before desilter. Different from the Shale Shaker separating solids by screen, desander removes those abrasive solids from the drilling mud by centrifugal force. Due to different density of solid and liquid, the very fine solid which cannot be removed by shakers could be separated out by desander. Desander is also the first one equipment to separate by using centrifugal force.
Models
Including 6 models, including KTDDS-388-1S, KTDDS-388-2S, KTDDS-353-2A, KTDDS-353-3H, KTDDS-355-2SH, KTDDS-355-3SH
|
Model |
KTDDS-388-1S/2S |
KTDDS-353-2A |
KTDDS-353-3H |
KTDDS-355-2SH/3SH |
|
Capacity |
120/240m3/h |
240m3/h (1056GPM) |
360m3/h(1584GPM) |
240/360m3/h |
|
Desander Size |
10 Inch |
|
|
|
|
Desander Qty |
1/2pcs |
2pcs |
3pcs |
2/3pcs |
|
Working Pressure |
0.25~0.4Mpa |
|
|
|
|
Feeding Size |
6 Inch |
|
|
|
|
Output Size |
8 Inch |
|
|
|
|
Bottom Shale Shaker Specs |
|
|
|
|
|
Shaker Model |
KTDS101A-SDC |
KTDS102A-MCS |
|
N/A |
|
Vibration Mode |
Linear Motion |
|
|
|
|
Vibration Motor |
2×0.75Kw |
2×1.72Kw |
|
|
|
Angle Adjust Motor |
N/A |
0.55Kw |
|
|
|
Screen Qty |
2pcs |
3pcs |
|
|
|
Screen Size: L×W |
750×900mm |
700×1250mm |
|
|
|
Screen Area |
1.35m2 |
2.63m2 |
|
|
|
Adjust G Force |
≤7.1G |
≤7.5G |
|
|
|
Vibration Amplitude |
3.92~5.62 |
4.14~5.96 |
|
|
|
Deck Angle Range |
+2° |
-1°~+5° (Eletric & Mechanical) |
|
|
|
EX Standard |
ExdIIBt4 / IEC EX/ ATEX |
|
|
|
|
Weight (Kg) |
1048/1105 |
1888 |
1964 |
502/559 |
|
Dimension (mm) |
1674×1707×1719 |
2419×2113×1608 |
2419×2113×2126 |
2193×900×1511 |
